2-6
2.5 Sensors
2.5.1 Sensor Locations
The following illustration shows the relative positions of the machine’s sensors.
HS
TS2
PES1
PES2
OPEN2
OPEN1
TRAYS
JAMC2
TS1
TXIL
DS2
DS1
APS
Thermistor
DPS
JAMC1
PSS
PDS
COVER-SW
