Muratec F-315 Field Engineering Manual

5-2 5-2
5.1 Maintenance schedule
 Scanning Section
Maintenance Cycle (pages)
Parts Name
Clean Replace
QTY Reference Page
Roller Separator*1
✓
60,000 or
2 years
1 5-24
Pad Separator*1
✓
60,000 or
2 years
1 5-36
Contact glass & Pane*2
Clean when
dirty
— 1 —
Sheet document press
(White sheet) *2
Clean when
dirty
— 1 5-82
Exposure Lamp*2
— 10,000 hours 1 5-19
Roller Feed
✓
100,000 1 5-25
Roller Exit
✓
100,000 1 5-27
*1 Replace the parts at the same time.
*2 It is not a maintenance parts. However, please replace when it becomes not works.
 Printer Section
Maintenance Cycle (pages)
Parts Name
Clean Replace
QTY Reference Page
Roller Transfer — 60,000 1 5-47
Roller Register
✓
100,000 1 5-48
Roller Pickup MP
✓
60,000 or
2 years
1 5-51
Printer Fuser — 100,000 1 5-52
Roller Exit
✓
100,000 1 5-53
Roller Pickup CST —
60,000 or
2 years
1 5-54
PAD Pressure CST —
60,000 or
2 years
1 5-54
Roller Feed Duplex
✓
60,000 or
2 years
1 5-61
 Developing Section
Maintenance Cycle (pages)
Parts Name
Clean Replace
QTY Reference Page
MFX-1950 Drum cartridge (US) — 20,000 1
MFX-1950 Drum cartridge
(Europe)
30,000 1
F-315 Drum cartridge (US) — 20,000 1
F-315 Drum cartridge (Europe) 20,000
MFX-1950 Toner cartridge (US) — 16,000 1
MFX-1950 Toner cartridge
(Europe)
— 16,000 1
F-315 Toner cartridge (US) — 7,500 1
F-315 Toner cartridge (Europe) — 15,000 1
Drum charge wire and LED print
head
✓
— 1
See Operating
Instructions
Note: “✓” means to clean the mechanism when a paper take-up or transport failure or print quality problems
occurs.
Note: The maintenance cycle (pages or years) may be shorter than the above value according to the environment
or usage of the machine, and the documents and paper that are used. The maintenance cycle (pages or
years) are not insured and early replacement of the parts may be needed to maintain the machine quality.
