5-22
5-22
PCB PSU / PCB NCU
1.
Re
mov
e the Cover option.
(See page
5-20)
2.
Ope
n the Cover front.
3.
Re
mov
e the Cover left mount
ing scr
e
w
, an
d then re
mov
e the Cover left.
Cover front
Cover left
4.
Re
mov
e f
our PCB NCU
mounting sc
rews.
5.
Dis
connect t
he connec
tor and t
hen remove the PCB NCU.
6.
Dis
connect t
wo connecto
rs.
7.
Re
mov
e the har
nes
s from c
ord clamp.
8.
Re
move the PCB PSU.
PCB PSU
PCB NCU
Clamp
233
235
