5-29
5-29
8.
S
lide out t
he Shaft g
uide
as shown below
.
Then rem
ov
e the FRAM
E SCANNER
.
Shaft guide
Frame scanner
FRAME SCANNER (F-315)
1.
Re
mov
e the Cover ADF base.
(See page 5-7)
2.
Re
mov
e the Cover top PPF
.
(See page 5-13)
3.
Re
mov
e the Cover lens.
(
See pag
e 5-18)
4.
Dis
connect t
he Flat h
ar
ness fr
om the conn
ector P1
on the PCB
CCD
.
5.
Re
lease two locking
tabs, and the
n remove the Core.
Flat harness
Core
Frame scanner
CCD PCB
P2
P1
240
242
