5-82
5-82
5.3.7
Applying the Sheet Document
Press
(MFX-1950 only)
1.
Ope
n the Cover platen.
2.
P
eel the s
eparator off
the dou
ble-coated tape o
f the
Sheet doc
ument press.
3.
P
lace the
Sheet doc
ument pr
ess, with th
e tape upwar
d, on the Pane.
4.
Make s
ure the
press edg
e is 1 mm
aw
a
y from
the doc
ument reference pos
ition of the Cover contac
t.
5.
Cl
ose the Cover platen.
Cover top
1mm
Cover contact
A
Sheet document press
1mm
293
295
