5-18
5-18
PCB INVERTER (F-3
15)
1.
Re
mov
e the Cover ADF base.
(See page 5-7)
2.
Re
mov
e the Cover top PPF
.
(See page 5-13)
3.
Re
mov
e the Cover lens.
(
See pag
e 5-19)
4.
R
emove the PCB IN
VERTER mountin
g scr
e
w
,
the
n disconnec
t two co
nnector
s and two l
ocking tabs,
and then the
PCB IN
VERTER.
PCB INVERTER
CN2
CN1
229
231
