5-28
5-28
FRAME SCANNER
(MFX-1950)
1.
Re
mov
e Cov
er platen.
(See
page 5-7)
2.
Re
mov
e the Cover top
.
(See page 5-
13)
3.
Re
mov
e the Cover lens.
(See p
age 5-17)
4.
Dis
connect t
he Flat h
ar
ness fr
om the conn
ector P1
on the PCB
CCD
.
5.
Re
lease two locking
tabs, and the
n remove the Core.
Flat harness
Core
Frame scanner
PCB CCD
P2
P1
6.
Dis
connect t
he Flat h
ar
ness
on the F
rame scann
er
.
7.
Re
mov
e the belt fr
om the
F
rame scanner
.
Belt
Belt
Flat harness
Frame scanner
Shaft guide
239
241
