5-61
5-61
ROLLER FEED DUPLEX A
1.
Re
mov
e the Cover jam acc
ess.
2.
Re
mov
e the Gui
de inner.
(See
page 5-47)
3.
Re
mov
e two Guide upp
er JAC mounting screws, and the
n remove the Guide upper
JA
C
.
Guide upper JAC
Cover jam access
4.
Re
mov
e the Belt
duplex from th
e Gear 20/2
5P
.
5.
Re
mov
e four E-rin
gs, and then r
emov
e the G
ear 20/
25P
.
Belt duplex
Gear 20/25P
Gear 20/25P
Bearing
Bearing
Bearing
E-ring
E-ring
E-rings
272
274
