Muratec F-315 Field Engineering Manual

5-15 5-15
5.2.2 PCBS
PCB PANEL 1(See page 5-16)
PCB CONNECT C(See page 5-23)
PCB PSU (See page 5-22)
PCB NCL (See page 5-22)
PCB INVERTER (See page 5-17)
PCB CCD (See page 5-28)
PCB CONNECT A (See page 5-21)
PCB MAIN (See page 5-20)
PCB CONNECT B(See page 5-21)
POWER-SUPPLY (See page 5-21)
