Muratec F-315 - Cover Tx Side B (Mfx)

5-8 5-8
COVER TX SIDE B (MFX-1950)
1. Open the Cover platen.
2. Remove the Cover TX side B mounting screw.
3. Close the Cover platen.
4. Open the Guide outer.
5. Release two locking tabs, and then remove the COVER TX SIDE B.
Cover TX side B
Guide outer
