• Layout function is the function which automatically determines the size of print data sent from a
PC and print it after locating on the roll media without futility.
• When the Layout item is set to "On", locate print data as per the following example.
(example) When the data is received in order of 1) A3 2) A2 3) A3, layout as shown in the
right drawing. Actual printing is performed in order of 2) A2 1), 3) A3 data.
• When the Layout item is set to "Off", print is performed sequentially after receiving print data.
• When sheet media is set, the layout function becomes disabled.
• The layout function might not become enabled depending on print data.
• For the operation of the setting menu, refer to “
4.5.2 Menu Setup Procedure”.
