RJ-900X series OPERATION MANUAL Before using
3-37
4. Connect the other network interface cable connector to your PC.
• Refer to the attached Operation Manual of your PC for the connection to your PC.
• For network setting on the side of the printer, refer to "
4.5.2 Menu Setup Procedure".
3.6.4 Connecting the USB cable
The procedure of USB cable connection is explained.
Connect the printer to your PC as shown in the following procedure.
• Do not connect USB cable before installing the printer driver. It cannot be correctly installed.
• When printing using USB connection, do not change the USB port on the computer.
If you have changed the USB port, you have to install the printer driver again
1. Insert the USB cable into the USB connector on the back of the printer.
No. Name
1
USB cable
2
USB connector
To Next Page
