Appendix RJ-900X series OPERATION MANUAL
7-2
7.1 Product specifications
7.1.1 Printer specifications
Items Specification
Model name RJ-901X RJ-900X
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurization grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/
ejection
Sheet media Front feed/Front ejection
Roll media Rear feed/Front ejection
Media Tracing paper, Color standard paper, Film, Coated paper, Gloss paper
Outer diameter
of the roll media
2 inch Under 100 mm Under 150 mm
3 inch Under 100 mm Under 150 mm
Maximum media
length
Sheet media 1200 mm 1600 mm
Roll media 50 m
Maximum media width 610 mm 1080 mm
Maximum print
length
Sheet media 1180 mm 1580 mm
Roll media 18 m
Maximum print width 604 mm 1074 mm
Print margin Sheet media Front: 3 mm, Back: 17mm, Left: 3 mm, Right: 3 mm
Roll media Front: 3 mm, Back: 17 mm, Left: 3 mm, Right: 3 mm
Media cut system Horizontal auto-cut system
Head height adjustment Standard/High (2 step adjustment)
Range accuracy Within ± 0.25 mm or ± 0.1 % of the moving distance
•Use media: Matte film 50 m
•Use temperature: 20°C
•Use humidity: 60 %
•Print mode: High quality
Perpendicularity For moving distance (500.0 mm), within ±0.1 mm
•Use media: Matte film 50 m
•Use temperature: 20 °C
•Use humidity: 60 %
•Print mode: High quality
CPU 64Bit RISC CPU
Memory 256MB
Command
MH-GL, MH-GL/2, MH-RTL（RTL-PASS）
Font Vector font (JIS first level, second level, in accordance with 1990 version)
