MUTOH DrafStation RJ-901X User Manual

RJ-900X series OPERATION MANUAL
A-3
Setup menu diagram (2/4)
To Setup menu diagram(1/4)
Command
PenSetup
To Setup menu diagram(3/4)
When the panel is set in the pen
priority item
Pen0Width-Pen15Width
Pen0Color-Pen15Color
Pen0Tone-Pen15Tone
All Width
All Color
All Tone
Command
Origin
Step
Position
Terminator
ImageReso.
OnlineTimer
Merge
Quality
PenPrior
PenTone
0.10.mm
0.13mm
0.18mm
0.25mm
0.35mm
0.50mm
0.60mm
0.70mm
0.80mm
0.90mm
1.00mm
0/1/2/3/4/5 - 255
(When color is set)
0%/10%/20% - 100%
(When Black & White is set)
0.10mm
0.13mm
0.18mm
0.25mm
0.35mm
0.50mm
0.60mm
0.70mm
0.80mm
0.90mm
1.00mm
0/1/2/3/4/5 - 255
(When color is set)
0%/10%/20% - 100%
(when pen tone is enabled)
<MH-GL,GL/2>
MH-GL/2
<Center>
LL
<0.025mm>
0.010mm
<P1>
LL
Full
Normal
<Special>
300dpi
<360dpi>
600dpi
720dpi
1200dpi
1440dpi
Off
2s-<30s>-800s
<Last>
Mix
<ThinLine>
FillIn
Panel
<Command>
Valid
<Invalid>
A
A
