RJ-900X series OPERATION MANUAL Before using
3-23
5. Insert the sheet media into the media feed slot on the printer front side.
6. Align the right end of media to the media loading mark, and align the front edge to step of the platen
respectively.
NOTE
• If the sheet media right end shifts either to the right or the left from the loading mark, it would
become as media loading error without media being detected.
Load the media within the ±5 mm range from the loading mark.
No. Name
1
Sheet media
No. Name
1
Sheet media
2
Media loading mark
3
Platen step
1
2
1
1
3
2
3
