User’s Guide – Ultima cutting plotter
22 AP-75032, Rev 2.2, 20/04/07
Step 12: The status bar starts moving.
Step 13: Press the [Start] button to begin the updating
Step 14: Select the right “.bin” file.
Step 15: The Ultima gives a beep and "Connection with ULTIMA established! Please wait..." is shown in
the update tool.
Step 16: After 13 seconds the message "Sending firmware to ULTIMA!! Please wait...!" appears in the
update tool.
Step 17: The progress bar now starts increasing.
Step 18: The first seconds the progress bar colours red and green. Afterwards the progress bar is black.
Notes
Please note that you passed the critical section of updating when the progress bar is black. When the
machine is shut down in the critical section of the update we refer to the section “When you shut down the
Ultima inside the critical section”.
Step 19: After 1 minute the update finishes with the text "Firmware update successful, restart the
ULTIMA!" on the Ultima update tool.
Step 20: Power OFF the Ultima cutting plotter.
Notes
Please perform a “Code Update” after a firmware upgrade. Without performing a “Code Update”, the panel
keyboard remains in the old firmware version.
Step 21: Restart the Ultima cutting plotter.
