User’s Guide – Ultima cutting plotter
44 AP-75032, Rev 2.2, 20/04/07
In case you selected ‘BCode Single’
Step 15 : Press the [MENU ▲] key to choose BCode Single.
Step 16 : Press the [CONTOUR CUTTING] button again.
Contourcutting:
→ Repeat Mode
Start Aligning
Step 17 : With the [MENU ▲] key to choose “Single Scan” or “Repeat Mode”.
Notes
> Single Scan: The command will be given to start scanning the bar code of the first / next bounding box
ONLY, from roll or sheet. After finishing this single job, the Ultima returns into the Ready status.
> Repeat Mode: AUTOMATICALLY all succeeding frames will be scanned and contour cut as well, until the
end of roll is reached.
Step 18 : Press the [ENTER] key to start.
In case you selected ‘BCode Multi’
Step 15 : Press the [MENU ▲] key to choose BCode Multi.
Step 16 : Press the [CONTOUR CUTTING] button again.
Contourcutting:
→ Single Scan
Start Aligning
Step 17 : With the [MENU▲] key to choose “Single Scan” or “Repeat Mode”.
Notes
> Single Scan: The command will be given to start scanning the bar code of the first / next bounding box
ONLY, from roll or sheet. After finishing this single job, the Ultima returns into the Ready status.
> Repeat Mode: AUTOMATICALLY all succeeding frames will be scanned and contour cut as well, until the
end of roll is reached.
Step 18 : Press the [ENTER] key to start.
