User’s Guide – Ultima cutting plotter
43 AP-75032, Rev 2.2, 20/04/07
In case you selected ‘Auto No BCode’.
Step 15 : The Ultima cutting plotter will automatically measure the four alignments points.
In case you selected ‘Manual’.
Step 15 : After pressing the [ENTER] key following message will appear on the display.
Manual alignment
method
please select
the point
Step 16 : Use the [ARROW] keys to select the first alignment point (P1). Press the [ENTER] key to
perform.
Step 17 : The Ultima cutting plotter will move the head toward the second alignment point. On the display
following message will appear.
Manual alignment
method
please select
the point
Step 18 : Use the [ARROW] keys to select the second alignment point (P2). Press the [ENTER] key to
perform.
Step 19 : The Ultima cutting plotter will move the head toward the third alignment point. On the display
following message will appear.
Manual alignment
method
please select
the point
Step 20 : Use the [ARROW] keys to select the fourth alignment point (P4). Press the [ENTER] key to
perform
Step 21 : The Ultima cutting plotter will move the head toward the fourth alignment point. On the display
following message will appear.
Manual alignment
method
please select
the point
Step 22 : Use the [ARROW] keys to select the third alignment point (P3). Press the [ENTER] key to
perform.
Step 23 : Manual alignment is completed.
Notes
Make sure to keep the order of the alignment points. P1, P2, P4 and then P 3
