User’s Guide ValueJet 1608 HS
Basics
AP-75810 - Revision 2.0 45
3
Step 10: Slide the media holder plates from both sides of the platen to set them.
Step 11: If the media retainers are not used, return them to their initial position.
Note
 Do not use the media retainers when the media thickness is larger then 0.5mm.
Caution
 If media is jammed when using media retainers, stop using the printer and do
not remove the jammed media by force. This could deform the media retainers.
 Using the printer with deformed media retainers could damage the grid roller or
print head.
 If the media retainers are deformed, contact your local Mutoh dealer.
1
1
4
3
2
1
4
2
3
1
1
2
1
2
