Before using VJ-1628X OPERATION MANUAL
106 3.6 Test print
• After printing is complete, “Attaching instrument [ENTER]” is displayed on the operation panel.
7. Press the [Enter] key.
• “Wait for a while...” is displayed on the operation panel.
• The print head moves to the left.
• “Open left mainte. cover.” is displayed on the operation panel.
No. Name
1
Color Patches
2
Media Type
3
Preset Heater Temperature
4
Head Temperature Information
User Type = Type 3 Head Temp. =25˚CPre Heater = 42˚C
Praten Heater = 42˚C
Dryer = 42˚C
0.30.30.40.10.21.21.10.60.60.50.10.60.6 0.2
dE(94) < 1.0: No discernable difference in color.
dE(94) < 3.2: Minimally discernable color difference for colors viewed side-by-side.
dE(94) < 3.2: Minimally discernable color difference for colors in close proximity, not side-by-side.
2
1
3 4
