VJ-1628X OPERATION MANUAL Before using
3.6 Test print 107
8. Open the maintenance cover on the left of the printer.
• "Remove connector cap and attach instrument [ENTER]" is displayed on the operation
panel.
• When a certain time has passed without opening the maintenance cover, the print head returns
toward the right side of the printer to protect the print head. "Attaching instrument [ENTER]" is
displayed. Restart from the Step 8.
9. Firmly pinch the tabs on both sides of the connector cap with your fingers, pull the connector cap
forward to remove it from the print head.
No. Name
1
Maintenance Cover
No. Name
1
Connector cap
2
Tabs
3
Print head section
To Next Page
