Before using VJ-1628X OPERATION MANUAL
108 3.6 Test print
10. Press the release buttons on both sides of spectrophotometer, install it to the connector at the print
head.
• Make sure that spectrophotometer is NOT installed at an angle, and that there is no gap between the
connector and spectrophotometer.
11. Press the [Enter] key.
• “Wait for a while...” is displayed on the operation panel.
• The printer checks the connection between the printer and spectrophotometer.
• “Set white plate then close left maintenance cover.” is displayed on the operation panel.
No. Name
1
Spectrophotometer
2
Release buttons
3
Print head section
4
Connector
To Next Page
