VJ-1628X OPERATION MANUAL Before using
3.7 Print quality adjustment 141
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 21.
• “12” is selected in the following pattern.
• “11” represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
5. “PatternA: 11” is displayed on Operation panel.
6. Press the [+] key or [-] key on Operation panel to enter the number that you selected in Step 4.
• When you press the [Cancel] key on Operation panel, the setting value is not entered and the display
returns to “Adj.2: RoughPtn. ALL”.
111213
Not adequate Adequate
Not adequate
To Next Page
