Before using VJ-1628X OPERATION MANUAL
148 3.7 Print quality adjustment
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 7.
• “6” is selected in the following pattern.
• “4” represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
5. “PatternA: 4” is displayed on Operation panel.
6. Press the [+] key or [-] key on Operation panel to enter the number that you selected in Step 4.
• When you press the [Cancel] key on Operation panel, the display returns to “Adj.9: Fine Ptn. ALL”.
Not adequate Adequate
Not adequate
To Next Page
