Handling the printer VJ-1628X OPERATION MANUAL
190 4.5 Using Spectrophotometer
1. Connect the printer and computer.
3.8 Connecting the printer to PC
2. Turn the printer ON.
3. Set the media.
3.5 Loading media
4. Set the user type setting.
3.5.3 Setting the User Type Setting
• When the user type setting and media initial operation are complete, “Ready to Print” is
displayed on Operation panel.
5. Start RIP software to print and measure the color target.
• For the setting and operations of the RIP software, refer to its operation manual.
• The printer starts printing the color target.
• “Printing” is displayed on Operation panel.
• After printing is complete, “Attaching instrument [ENTER]” is displayed on Operation panel.
• Do not open the covers or move media loading lever during printing.
6. Press the [Enter] key.
• “Wait for a while...” is displayed on Operation panel.
• Print head moves to the left.
• “Open left mainte. cover.”is displayed on Operation panel.
To Next Page
