VJ-1628X OPERATION MANUAL Panel setup menu
5.1 Setup menu 209
Standard Adjust Print menu
Adjusts only the print mode in the user type setting which is currently set.
Custom Adjust Print menu
Perform adjustment for all patterns (A to F).
All print modes will be adjusted.
Setup item Setting Description
Adj. Print1: Standard Confirm ptn. Print the test pattern for the alignment.
Check before adjusting.
3.7.1.1 Standard confirmation pattern
Rough pattern Perform this when the degree of misalignment is big.
Print Adjust pattern and enter the set value.
3.7.1.2 Standard rough adjustment pattern
Fine pattern Perform this when the degree of misalignment is small.
Print Adjust pattern and enter the set value.
3.7.1.3 Standard micro adjustment pattern
— • [Cancel] key: shifts to the previous menu.
5.1.1.1.2 Adjust Print menu
Setup item Setting Description
Adj. Print2 : Custom Confirm ptn. The test patterns of A to F will be printed for Adjust print.
Check before adjusting.
3.7.2.1 Custom confirmation pattern
Rough Ptn. ALL Perform this when the degree of misalignment is big.
Print Adjust patterns A to F and enter the set values.
3.7.2.2.1 Rough Pattern ALL
Rough Pattern A to F When the degree of misalign is big, print out an adjust pattern
selected from A to F and enter the value.
3.7.2.2.2 Rough Pattern A to F
Fine Ptn. ALL Perform this when the degree of misalignment is small.
Print Adjust patterns A to F and enter the set values.
3.7.2.3.1 Fine Pattern ALL
Fine PatternA to F When the degree of misalign is small, print out an adjust
pattern selected from A to F and enter the value.
3.7.2.3.2 Fine Pattern A to F
— • [Cancel] key: shifts to the previous menu.
5.1 Setup menu
