VJ-1628X OPERATION MANUAL Panel setup menu
5.1 Setup menu 211
(2) Initial Change menu
Sets up Initial Adjust Change.
(3) Confirm Print menu
Performs Confirm Print.
(4) Micro Print menu
Performs Micro Adjustment Print.
Setup item Setting Description
Init. The setting value of
“FeedLength” in the initial
adjustment printing ±50.0mm
Sets up Initial Adjust Change.
Example: When the value of “FeedLength” in the initial
adjustment printing is set to 250mm, the adjustment range of
this menu is 200mm to 300mm.
— • [Enter] key: saves the setting and shifts to the previous
menu.
• [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.3 Media feed compensation
Setup item Setting Description
FeedLength 100mm to <250mm> to
500mm
Changes the length (feed length) of the media feed direction
for Confirm Print.
• [Enter] key:
Determines the setting.
“Printing” is displayed on Operation panel and initial adjust
print starts.
After printing, the printer enters Normal.
— • [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.3 Media feed compensation
Setup item Setting Description
Micro Print -5.00% to <0.00%> to 5.00%
(After printing)
• Prints a micro adjustment pattern based on the currently set
micro adjustment value with each of the following values
applied to it.
±0.10%、±0.20%、±0.50%、±0.80%、±1.20%
After printing, enter a micro adjustment value in the following
range:
• -5.00% ～ <0.00%> ～ 5.00%
— • [Cancel] key: shifts to the previous menu.
If during printing, printing will be paused.
5.1 Setup menu
