VJ-1628X OPERATION MANUAL Product overview
2.2 Names of parts and functions 31
No. Name Normal Setup menu display
1 [Menu] key Shifts to the Setup menu. Shifts from Setup menu display to Normal.
2 [Enter] key Restarts printing while printing is being
suspended.
• Select the menu to set, and shift to the next
hierarchy.
• The setting is determined and saved.
[Cutting] key Cuts the media when pressed for more than
two seconds.
—
3 [Pause] key Pauses printing. —
[Cancel] key • When printing:
When pressed for more than two seconds,
forcefully terminates printing and deletes
one file of the remaining data.
• When receiving or analyzing data:
When pressed for more than two seconds,
deletes the data already received and
analyzed.
• Returns to the previous menu hierarchy.
Changes made in the setting are discarded.
• Shifts from Setup menu display to Normal.
4 [<] key — —
[Nozzle Check] key Press and hold this key for two seconds or
more to perform Nozzle Check printing.
—
5 [>] key • Sets Cleaning Mode.
• The lamp of Cleaning Mode that you set
lights up in green.
Shifts the menu in the lower hierarchy.
[Cleaning] key When pressed for more than two seconds,
cleaning starts.
—
6[Backward↑] key The media is fed in the reverse direction. —
[+] key — • Changes the displayed menu to the forward
direction.
• The setting is changed to the reverse
direction.
• The numeric value is increased during
numerical input.
7[Forward↓] key Media is fed in the forward direction. —
[–] key — • Changes the displayed menu to the reverse
direction.
• Changes the setting in the forward
direction.
• The numeric value is decreased during
numerical input.
8 [Power] key Turns the printer ON/OFF. Turns the printer ON/OFF.
To Next Page
