VJ-1628X OPERATION MANUAL Before using
3.5 Loading media 87
a. Loosen Fixing levers of the right and left Roll media holders(), and move the roll media to left
or right().
b. After moving the roll media(), fix it with Fixing levers of the right and left Roll media holders
().
• When tightening Fixing lever, press Roll media holder toward the printer. If you do not press Roll
media holder, Fixing lever may not be completely locked because of the weight of the roll media.
No. Name
1 Roll media holder (Left)
2 Roll media holder (Right)
3 Roll media
4 Fixing lever
To Next Page
