Before using VJ-1324X OPERATION MANUAL
102 3.6 Adjust Print
• An micro adjust print pattern is printed.
(Starts printing after warming up is complete.)
• For the Adjust print pattern, the same patterns will be printed repeatedly on both sides and center
of the media.
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 7.
• “6” is selected in the next printing sample.
NOTE
• “4” represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line.
• “PatternA: 4” is displayed on Operation panel.
Pattern name
1234567
Print Information
Bi dir
Low H.Height
normal speed
large drop family
Not adequate Adequate
Not adequate
