Handling the printer VJ-1324X OPERATION MANUAL
116 4.2 Media
2. Performs Initial Print.
a. Press the [Enter] key on the operation panel.
• “Feed Length: 250 mm” is displayed on the operation panel.
TIP
•The length of media that is fed (feeding length) for Initial Print is normally set at 250 mm.
•If you increase the feeding length, the accuracy of the Media feed adjustment improves.
To change the feeding length, press the [+] key or [-] key on the operation panel and change the set value.
b. Press the [Enter] key on the operation panel.
• “Printing” is displayed on the operation panel.
• Starts Initial Print.
• When the Initial Print is complete, the printer enters Normal.
c. After the Initial Print, the media is cut.
4.4.3 Cutting media
3. Measure the distance between the two pluses (+) in the Initial Print using a ruler.
No. Name
1 Feed length
2 Media feeding direction
2
1
1
