Before using VJ-1324X OPERATION MANUAL
92 3.6 Adjust Print
4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the
number from 1 to 11 that is not out of alignment.
• “9” is selected in the following pattern.
• “6” is the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
• “PatternA: 6” is displayed on the operation panel.
5. Press the [+] key or [–] key to enter the number that you selected in Step 4.
• When you press the [Cancel] key on Operation panel, the setting value is not entered and the display
returns to “Adj.2: RoughPtn. ALL”.
8910
Not adequate Adequate
Not adequate
To Next Page
