Bodywork
Remove the right and left suction duct unions (1)
before removing the airbox.
Air filter compartment side panels
Remove the left and right air filter compartment side
panels by unscrewing the two relative screws (1).
Before reassembly, check the integrity of the elastic
nuts and replace if necessary.
- 19 -
