Maintenance
- 11 -
B
35 N•m
2
2
1
1
35 N•m
Replace the oil filter and put the cover back on.
On the oil discharge plug there is a magnet to attract
any metal residues that could form in the engine during
rotation.
Before replacing the cap, make sure it is completely
clean. Replace the sealing washer with a new one.
Screw in the oil discharge plug and tighten it to the
specified torque.
Torque pressure oil discharge plug: 35 N·m
Pour around 3 kg of engine oil (as specified in the table
on page B-9) into the filling hole.
Close the filler hole using the appropriate cap.
Before replacing the filler cap, grease the O-ring (1)
with silicone grease (see figure).
Tighten the cap (2) to the prescribed tightening torque.
Tightening torque: 35 N·m
