Suspension and wheels
F
- 33 -
Remove the anti-dust seal, the internal bearing ring
and the ball bearing ring.
Steering base removal
(F4 R - F4 MY13)
Using the specific tool, loosen the ring nut of the stee-
ring spindle, supporting the base of the steering head
with a hand.
Special tool No. 800091645
Remove the screw ring previously slackened and
remove the steering base complete with the pin.
Remove the anti-dust seal, the internal bearing ring
and the ball bearing ring.
