Suspension and wheels
F
- 34 -
Disassembly of the lower steering bearing
If it is necessary to replace the steering base comple-
te with pin, you must remove the parts of the lower
steering bearing according to the procedure described
as follows.
Remove the internal bearing ting and the ball bearing
ring from the pin of the steering base previously remo-
ved from the bike.
Place the steering base on the corresponding support
plate (special tool).
Special tool No. 800097888
Insert the steering pin bearing extractor (special tool)
on the steering base pin.
Special tool No. 800097889
Couple the two half-shells on the extractor as shown in
the picture.
Insert the extractor ring on the half-shells.
Special tool No. 800097889
Rotate the extractor nut by using a 27 mm spanner key
until the anti-dust seal detaches from the steering pin.
Remove the complete tool (code no. 800097889) from
the steering pin and recover the anti-dust seal.
The removed parts will have to be reused in the fol-
lowing assembly operations of the new steering base.
