Suspension and wheels
F
- 54 -
Lower chain guard removal
Remove the three socket head screws (1) of the lower
chain guard.
Remove the lower chain guard, taking care to recover
the internal bushes.
Exhaust protection removal
Remove the three screws (1) that fix the protection
onto the exhaust group.
1
Silencers Removal
Remove the closing wiring cover on the heat guard,
levering with a screwdriver.
1
