Suspension and wheels
F
- 58 -
Remove the silencer unit from the exhausts.
Upper chain guard removal
Remove the screw complete with ferrule.
Extract the chain guard by pulling it out from the back
part of the wheel (see figure) so that it is freed from its
position on the swingarm.
CHAIN REMOVAL (Regina 525 ZRPK)
Cut the chain utilising the special tool.
Special tool no. 8000B1439.
Unscrew bolt (1) so that the tip is retracted into the hex
nut.
This tool coud be applied in any point of
the lower section of the chain.
NOTE
2
1
