- 16 -
Brakes
H
REPLACING THE BRAKE FLUID RESERVOIR
(F4 S - F4 FT - F4 R - F4 MY13)
Loosen fixing screw (1) and then remove the brake
fluid reservoir.
1
Remove the connectors of the electrical system.
Remove the fixing screws that fix the pump to the han-
dlebar.
Open the clamp.
Push down to remove the pump from the reference pin.
When reassembling the pump, fix and tighten the fixing
screws at the prescribed torque.
Torque pressure: 7÷9 Nm
7÷9 N•m
