NETGEAR UTM9S Reference Manual

Virtual Private Networking Using IPSec Connections
259
ProSecure Unified Threat Management (UTM) Appliance
• Use the Connection Panel screen. On the main menu of the Configuration Panel
screen, select Tools > Connection Panel to open the Connection Panel screen.
Perform one of the following tasks:
- Double-click Gateway-Tunnel.
- Right-click Gateway-Tunnel, and select Open tunnel.
- Click Gateway-Tunnel, and press Ctrl+O.
Figure 157.
• Use the system-tray icon. Right-click the system tray icon, and select Open tunnel
‘Tunnel’.
Figure 158.
Whichever way you choose to open the tunnel, when the tunnel opens successfully, the
Tunnel opened message displays above the system tray:
Figure 159.
Once launched, the VPN client displays an icon in the system tray that indicates whether or
not a tunnel is opened, using a color code:
Figure 160.
Purple icon:
no VPN tunnel opened
Green icon:
at least one VPN tunnel opened
