Manually Configuring Internet and WAN Settings
90
ProSecure Unified Threat Management (UTM) Appliance
Configure Advanced WAN Options
The advanced options include configuring the maximum transmission unit (MTU) size, the
port speed, and the UTM’s MAC address, and setting a rate limit on the traffic that is being
forwarded by the UTM.
Note: You can also configure the failure detection method for the
auto-rollover mode on the Advanced screen. This procedure is
discussed in Configure the Failure Detection Method on page 79.
 To configure advanced WAN options:
1. Select Network Config > WAN Settings.
2. Click the Edit button in the Action column of the WAN interface for which you want to
configure the advanced options. The WAN ISP Settings screen displays (see Figure 37 on
page 69, which shows the WAN1 ISP Settings screen of the UTM50 as an example).
3. Click the Advanced option arrow in the upper right of the screen. The WAN Advanced
Options screen displays for the WAN interface that you selected. (The following figure shows
the WAN1 Advanced Options screen of the UTM50 as an example.)
Figure 51.
