D. ReadyNAS Integration

This appendix describes how to set up a UTM9S with a NETGEAR ReadyNAS. This appendix

includes the following sections:

• Supported ReadyNAS Models

• Install the UTM9S Add-On on the ReadyNAS

• Connect to the ReadyNAS on the UTM9S

Supported ReadyNAS Models

The following ReadyNAS models are supported for integration with the UTM9S:

• ReadyNAS 1500

• ReadyNAS 2100

• ReadyNAS 3100

• ReadyNAS 3200

• ReadyNAS 4200

• ReadyNAS Ultra 2/Plus

• ReadyNAS Ultra 4/Plus

• ReadyNAS Ultra 6/Plus

• ReadyNAS Pro 2

• ReadyNAS Pro 4

• ReadyNAS Pro 6

• ReadyNAS Pro Business Edition

• ReadyNAS Pro Pioneer Edition

• ReadyNAS NVX

• ReadyNAS NVX Pioneer Edition
