Monitoring System Access and Performance
419
ProSecure Unified Threat Management (UTM) Appliance
Enable the WAN Traffic Meter
If your ISP charges by traffic volume over a given period of time, or if you want to study traffic
types over a period of time, you can activate the traffic meter for one or more WAN ports.
 To monitor traffic limits on each of the WAN ports:
1. Select Network Config > WAN Metering. On the multiple WAN port models, the WAN
Metering tabs display, with the WAN1 Traffic Meter screen in view (the following figure
shows the WAN1 Traffic Meter screen of the UTM50). On the single WAN port models,
the WAN Traffic Meter screen displays.
The Internet Traffic Statistics section in the lower part of the screen displays statistics on
Internet traffic through the WAN port. If you have not enabled the traffic meter, these
statistics are not available.
Figure 251.
2. Enter the settings as explained in the following table:
