Introduction
29
ProSecure Unified Threat Management (UTM) Appliance
Test LED On (amber) during
startup
Test mode. The UTM is initializing. After approximately 2 minutes, when the
UTM has completed its initialization, the Test LED goes off.
On (amber) during
any other time
The initialization has failed, or a hardware failure has occurred.
Blinking (amber) The UTM is writing to flash memory (during upgrading or resetting to
defaults).
Off The UTM has booted successfully.
USB LED Nonfunctioning The USB port is currently not operable on the UTM9S.
LAN ports
Left LED Off The LAN port has no link.
On (green) The LAN port has detected a link with a connected Ethernet device.
Blinking (green) Data is being transmitted or received by the LAN port.
Right LED Off The LAN port is operating at 10 Mbps.
On (amber) The LAN port is operating at 100 Mbps.
On (green) The LAN port is operating at 1000 Mbps.
DMZ LED Off Port 4 is operating as a normal LAN port.
On (green) Port 4 is operating as a dedicated hardware DMZ port.
WAN ports
Left LED Off The WAN port has no physical link, that is, no Ethernet cable is plugged into
the UTM.
On (green) The WAN port has a valid connection with a device that provides an Internet
connection.
Blinking (green) Data is being transmitted or received by the WAN port.
Right LED Off The WAN port is operating at 10 Mbps.
On (amber) The WAN port is operating at 100 Mbps.
On (green) The WAN port is operating at 1000 Mbps.
Active LED Off The WAN port either is not enabled or has no link to the Internet.
On (green) The WAN port has a valid Internet connection.
Wireless module
Module
Status LED
Off The module is not enabled.
On (green) The module is enabled.
Table 3. LED descriptions UTM9S (continued)
LED Activity Description
