Wireless Module for the UTM9S
547
ProSecure Unified Threat Management (UTM) Appliance
Figure 320.
The following table explains the fields of the Access Point Status screen.
To change the poll interval period, enter a new value in the Poll Interval field, and then
click Set interval. To stop polling, click Stop.
Table 143. Access Point Status screen fields
Item Description
AP Statistics
AP Name The name for the virtual access point (VAP) is ap1.
Packets The number of received (Rx) and transmitted (Tx) packets on the access point in bytes.
Bytes The number of received (Rx) and transmitted (Tx) bytes on the access point.
Errors The number of received (Rx) and transmitted (Tx) errors on the access point.
Dropped The number of received (Rx) and transmitted (Tx) dropped packets on the access point.
Multicast The number of received (Rx) and transmitted (Tx) multicast packets on the access point.
Collisions The number of signal collisions that have occurred on the access point. A collision occurs
when the access point attempts to send data at the same time as a wireless station that is
connected to the access point.
Connected Clients
MAC Address The MAC address of the client.
Radio The radio to which the client is connected (2.4GHz or 5GHz).
Security The type of security that the client is using (Open, WEP, WPA, WPA2, or WPA+WPA2).
Encryption The type of encryption that the client is using (None, TKIP, AES, or TKIP+AES).
