Configure System Information
115
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
The following table describes the nonconfigurable DAI statistics information that is
displayed.
6. Click the Update button to update the data on the page with the latest DAI statistics from the
device.
7. Click the Clear button to clear the DAI statistics.
Field Description
VLAN The enabled VLAN ID for which statistics are displayed.
DHCP Drops The number of ARP packets that were dropped by DAI because no matching DHCP
snooping binding entry was found.
DHCP Permits The number of ARP packets that were forwarded by DAI because a matching DHCP
snooping binding was entry found.
ACL Drops The number of ARP packets that were dropped by DAI because no matching ARP
ACL rule was found for this VLAN and the static flag is set on this VLAN.
ACL Permits The number of ARP packets that were permitted by DAI because a matching ARP
ACL rule was found for this VLAN.
Bad Source MAC The number of ARP packets that were dropped by DAI as the sender MAC address
in the ARP packet did not match the source MAC in the Ethernet header.
Bad Dest MAC The number of ARP packets that were dropped by DAI as the target MAC address in
the ARP reply packet did not match the destination MAC in the Ethernet header.
Invalid IP The number of ARP packets that were dropped by DAI as the sender IP address in
the ARP packet, or target IP address in the ARP reply packet, is not valid. Invalid
addresses include 0.0.0.0, 255.255.255.255, IP multicast addresses, class E
addresses (240.0.0.0/4), and loopback addresses (127.0.0.0/8).
Forwarded The number of valid ARP packets forwarded by DAI.
Dropped The number of invalid ARP packets dropped by DAI.
