NETGEAR XS708T User Manual

Configure Routing
230
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
7. Use the MAC Address field to specify the unicast MAC address of the device.
Enter the address as six two-digit hexadecimal numbers separated by colons, for
example, 00:06:29:32:81:40.
8. Click the Add button.
The static ARP entry is added to the switch.
9. Click the Apply button.
The updated configuration is sent to the switch. Configuration changes take effect
immediately.
The following table describes the nonconfigurable information displayed on the page. You
can navigate through the table by doing the following:
• From the Rows per page menu, select how many table entries are displayed per
page.
Possible values are 20, 50, 100, 200, and All. If you select All, the browser might be
slow to display the information.
• Click the < button to display the previous page of the table data entries.
• Click the > button to display the next page of the table data entries.
View or Globally Configure the ARP Table
You can change the configuration parameters for the Address Resolution Protocol (ARP)
table. You can also use this page to display the contents of the table.
Table 65. Routing VLANs ARP Cache information
Field Description
IP Address The IP address. It must be the IP address of a device on a subnet attached to one of the
switch’s existing routing interfaces.
Interface The routing interface associated with the ARP entry.
MAC Address The unicast MAC address of the device. The address is six two-digit hexadecimal
numbers separated by colons, for example, 00:06:29:32:81:40.
Type The type of ARP entry. Possible values are as follows:
• Local. An ARP entry associated with one of the switch’s routing interface’s MAC
addresses.
• Gateway. A dynamic ARP entry whose IP address is that of a router.
• Static. An ARP entry configured by the user.
• Dynamic. An ARP entry that was learned by the router.
Age Age since the entry was last refreshed in the ARP table (in seconds).

NETGEAR XS708T Specifications

General

Switch type	Managed
Switch layer	L2+/L3
Quality of Service (QoS) support	Yes
USB 2.0 ports quantity	1
SFP+ module slots quantity	2
Installed SFP modules quantity	-
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Basic switching RJ-45 Ethernet ports quantity	8
Certification	CE, FCC Cl. A, VCCI Cl. A, Cl. A EN 55022 (CISPR 22), Cl. A C-Tick, EN 55024, CCC
Product color	Black
LED indicators	Activity, Link, Power
Number of fans	1 fan(s)
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN
Cable types supported	Cat5e, Cat6, Cat6a, Cat7
Copper ethernet cabling technology	10GBASE-T
Noise level	29.1 dB
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	600 MHz
Mean time between failures (MTBF)	276832 h
Jumbo frames	9000
Latency (10 Gbps)	3.012 µs
MAC address table	16000 entries
Packet buffer memory	2 MB
Number of static routes	32
DHCP features	DHCP server, DHCP client
Security algorithms	802.1x RADIUS
Access Control List (ACL) rules	100
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	96 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2980 g
