Monitor the System
382
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
The following table describes the event log information that is displayed on the page.
Format of the Messages
Messages are displayed in the following format:
• Total number of messages: Number of persistent log messages displayed on the
switch.
• <15>Aug 24 05:34:05 STK0 MSTP[2110]: mspt_api.c(318) 237%%
Interface 12 transitioned to root state on message age timer
expiry
This example indicates a user-level message (1) with severity 7 (debug) on a system that is
not a chassis and generated by component MSTP running in thread ID 2110 on Aug 24
05:34:05 by line 318 of file mstp_api.c. This is the 237th message logged. Messages
logged to a collector or relay through syslog use a format identical to the previous message.
Configure Port Mirroring
Port mirroring selects the network traffic for analysis by a network analyzer. This is done for
specific ports of the switch. As such, many switch ports are configured as source ports and
one switch port is configured as a destination port. You can configure how traffic is mirrored
on a source port. Packets that are received on the source port, that are transmitted on a port,
or are both received and transmitted can be mirrored to the destination port.
The packet that is copied to the destination port is in the same format as the original packet
on the wire. This means that if the mirror is copying a received packet, the copied packet is
VLAN tagged or untagged as it was received on the source port. If the mirror is copying a
transmitted packet, the copied packet is VLAN tagged or untagged as it is being transmitted
on the source port.
The Port Mirroring page allows you to view and configure port mirroring on the system.
Table 93. Event Logs information
Field Description
Entry The sequence number of the event.
Type The type of the event.
File Name The file in which the event originated.
Line The line number of the event.
Task Id The task ID of the event.
Code The event code.
Time The time this event occurred.
