Page #165 background imageLoading...
Page #165 background image
Configure Switching
165
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
View the MFDB Statistics
To view the MFDB statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see Change the Default IP Address of the
Switch on page 10.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is password.
The System Information page displays.
5. Select Switching > Multicast > MFDB > MFDB Statistics.
Table 43. MFDB table information
Field Description
MAC Address The multicast MAC address for which you requested data.
VLAN ID The VLAN ID to which the multicast MAC address is related.
Type This displays the type of the entry. Static entries are those that are
configured by the end user. Dynamic entries are added to the table as a
result of a learning process or protocol.
Component This is the component that is responsible for this entry in the Multicast
Forwarding Database. Possible values are IGMP snooping, GMRP, Static
Filtering and MLD snooping.
Description The text description of this multicast table entry. Possible values are
Management Configured, Network Configured, and Network Assisted.
Forwarding Interfaces The resultant forwarding list is derived from combining all the forwarding
interfaces and removing the interfaces that are listed as the static filtering
interfaces.
