Maintenance
401
XS708T, XS712Tv2, and XS716T Smart Managed Pro Switch User Manual
The following table describes the information available on the page.
Troubleshooting
You can use a ping or a traceroute, and you can perform a memory dump.
The Troubleshooting page contains links to the features described in the following sections:
• Ping IPv4 on page 401
• Ping IPv6 on page 403
• Traceroute IPv4 on page 404
• Traceroute IPv6 on page 406
• Remote Diagnostics on page 408
• Configure Memory Dump Settings and Perform a Full Memory Dump on page 409
Ping IPv4
Use this page to tell the switch to send a ping request to a specified IP address. You can use
this to check whether the switch can communicate with a particular IP station. When you click
the Apply button, the switch sends a specified number of ping requests and the results are
displayed.
If a reply to the ping is not received, the following message displays:
Tx = Count, Rx = 0 Min/Max/Avg RTT = 0/0/0 msec
If a reply to the ping is received, the following message displays:
Reply From a.b.c.d: icmp_seq = 0. time= xyz usec.
Reply From a.b.c.d: icmp_seq = 1. time= abc usec.
Reply From a.b.c.d: icmp_seq = 2. time= def usec.
Tx = count, Rx = count Min/Max/Avg RTT = xyz/abc/def msec
Table 94. Dual Image Status information
Field Description
Image1 Ver The version of the image1 code file.
Image2 Ver The version of the image2 code file.
Current-active The currently active image on this switch.
Next-active The image to be used on the next restart of this switch.
Image1 Description The description associated with the image1 code file.
Image2 Description The description associated with the image2 code file.
